Canon EOS 20D with Carl Zeiss Planar 1,7/50Canon EOS 20D



SPECIFICATIONS:

Lightweight and durable magnesium alloy body
Sensor 22.5 x 15.0 mm CMOS sensor, RGB Color Filter Array, Built-in fixed low-pass filter, 8.5 million total pixels, 8.2 million effective pixels,  3:2 aspect ratio
Image processor DIGIC II
Image sizes 3504 x 2336 (8.2 MP) - 2544 x 1696 (4.3 MP) - 1728 x 1152 (2.0 MP)
File formats RAW - JPEG (EXIF 2.21) - Fine / Normal -  RAW + JPEG (separate files)
Color space sRGB -  Adobe RGB
Lenses  Canon EF / EF-S lens mount 1.6x field of view crop
Focusing  9-point TTL  CMOS sensor AF working range: -0.5 - 18 EV (at 20C, ISO 100)
Focus modes  AI Focus AF,  One shot AF,  AI Servo AF,  Manual focus

AF point selection  Auto,  Manual,  Home position
AF assist  Stroboscopic flash,  4.0 m range (at center)
Metering  TTL 35 zone SPC,  Metering range: EV 1.0 - 20 EV (at 20C, ISO 100, 50 mm F1.4)
Metering modes Evaluative 35 zone,  Partial (9% at center), Center-weighted average,  Metering range: 1 - 20 EV (at 20C, ISO 100)
AE lock  Auto: One Shot AF with evaluative metering,  Manual: AE lock button,
AE bracketing  +/- 2.0 EV,  0.3 or 0.5 EV increments
Exposure compensation  +/-2.0 EV,  0.3 or 0.5 EV increments
ISO Sensitivity  Auto: 100, 200 or 400 - Manual 100, 200, 400, 800, 1,600 and 3200 with ISO speed extension
Shutter  Focal-plane shutter,  30 - 1/8000 sec,  0.3 or 0.5 EV increments,  Flash X-Sync: 1/250 sec,  Bulb
Aperture values  F1.0 - F91,  0.3 or 0.5 EV increments, Actual aperture range depends on lens used
White balance  Auto (3000 - 7000 K), Daylight (5200 K), Shade (7000 K), Cloudy (6000 K), Tungsten (3200 K), Fluorescent (4000 K), Flash (6000 K), Custom (2000 - 10000 K),  Kelvin (2800 - 10000 K in 100 K steps)
WB bracketing  +/-3 levels , 3 images, blue/amber or magenta/green bias
WB shift Blue (-9) To Amber (+9) -  Magenta (-9) to Green (+9)
Processing parameters
- Parameter 1 (contrast +1, sharpness +1, saturation +1, tone 0)
- Parameter 2 (contrast 0, sharpness 0, satuaration 0, tone 0)
- Set 1 (contrast, sharpness, saturation, tone)
- Set 2 (contrast, sharpness, saturation, tone)
- Set 3 (contrast, sharpness, saturation, tone)
- B&W (contrast, sharpness, filter, tone)
Custom parameters (Set 1 - 3) - Contrast (+/-2) - Sharpness (+/-2) -  Saturation (+/-2)  Color tone (+/-2)
Viewfinder  Eye-level pentaprism,  95% frame coverage,  Magnification: 0.9x (-1 diopter with 50 mm lens at infinity),  Eyepoint: 20 mm,  Dioptric adjustment: -3.0 to +1.0 diopter,  Precision matte screen
Viewfinder info  AF points, Focus confirmation light, Shutter speed, Aperture, Manual exposure, AE Lock, Exposure compensation amount, AEB level, Partial metering area, Flash ready, Red-eye reduction lamp on, High-speed sync, FE Lock, Flash compensation amount, Warnings, Maximum burst for continuous shooting, Buffer space
LCD monitor 1.8" TFT LCD - 118,000 pixels,  5 brightness levels, 10x zoom playback, Record review, Off, On (histogram via INFO button) 2, 4, 8 sec, Hold
Flash Auto pop-up E-TTL II auto flash FOV coverage up to 17 mm (27 mm equiv.), Guide number 13, Flash compensation +/-2.0 EV in 0.3 or 0.5 EV increments, X-Sync: 1/250 sec
External flash E-TTL II auto flash with EX-series Speedlites, Wireless multi-flash support, PC Sync
Shooting modes Auto, P = Program AE, Tv = Shutter priority AE, Av = Aperture priority AE, M = Manual, Auto depth-of-field, Portrait, Landscape, Close-up, Sports, Night portrait, Flash off
Drive modes  Single, Continuous: 5 fps up to 23 frames, Self-timer: 10 secs
Direct printing Canon Card Photo Printers, Canon Bubble Jet Printers with direct print function, PictBridge
Other features Orientation sensor, Automatically writes FAT16/FAT32 depending on capacity, LCD panel illumination, Auto rotation, On (playback uses orientation data in file header), Off
Playback mode Single image, Single image with info (inc. histogram), Magnified view (1.5 - 10x in 15 steps, browsable), 9 image index, Auto play, Image rotation,  Jump, Custom functions 18 custom functions with 50 settings
Menu languages English, French, German, Spanish, Italian, Dutch, Swedish, Norwegian, Danish, Finnish, Chinese, Japanese
Connectivity USB 2.0 Hi-Speed, Video out, N3 type wired remote control, PC Sync flash terminal
Storage Compact Flash Type I or II, Microdrive supported, FAT 12/16 and FAT 32 support, No CF card supplied
Power Lithium-Ion BP-511A rechargeable battery (supplied & charger), Supports BP-511 / BP-511A / BP-512 / BP-514, CR2016 Lithium battery (date/time backup),  Optional AC adapter, Portrait grip Via BP-E2 battery grip (option)
Dimensions 144 x 106 x 72 mm
Weight (no batt) 685 g  - (inc. batt) 770 g
Firmware User upgradable
